NEDB50

High-Speed Dock with M.2 SSD Slot
Docking station with built-in M.2 SSD slot, up to 140W power delivery, supports dual 6K@60Hz displays on Mac and dual 8K displays on Windows, up to 80/120Gbps bandwidth, 3× high-speed USB-C expansion ports, 2.5GbE networking, and driverless plug-and-play connectivity for Mac and PC.

Display Capabilities
Dual Display on Windows
Supports up to 2×8K@120Hz or 2×4K@144Hz displays.

Dual Display on Mac
Supports up to 2×6K@60Hz displays on Macs with M4/M5 chips or earlier Pro/Max chip models.

Single Display on Mac
Supports one high-performance display (up to 6K@60Hz) on base M1, M2, or M3 Mac models.

Ports & Connectivity
High-Speed USB-C Expansion Ports
Multiple downstream USB-C expansion ports supporting up to 100Gbps bandwidth via dynamic bandwidth boost technology.

Usage Scenarios
Connect up to two displays via USB-C or via USB-C to HDMI/DisplayPort adapters (sold separately).
Connect high-speed peripherals such as external storage devices, AI acceleration enclosures, or graphics expansion units.
Note: External graphics acceleration is not currently supported by macOS.

Display Connection Options
Displays with high-speed interface or USB-C ports can be connected using full-featured USB-C or high-speed interface cables.
Displays with HDMI or DisplayPort ports can be connected via USB-C to HDMI or USB-C to DisplayPort cables/adapters (sold separately).

USB-A Port
1× USB 3.2 Gen 2 Type-A port with up to 10Gbps data transfer for peripherals and storage devices.

Audio
Integrated 3.5mm audio jack for headphones or speakers.

Power Delivery
Host Charging
Provides up to 140W (28V/5A) USB Power Delivery to charge and power high-performance laptops.

Front Port Charging
Front-facing USB port supports high-power output for fast device charging.

Network & Storage
Ethernet
Integrated multi-gigabit Ethernet port (up to 2.5GbE) for stable, high-speed wired network connectivity.

Built-in Ultra-Fast Storage
Integrated internal SSD slot supporting storage speeds up to 6000MB/s under supported high-performance modes.
Note: Storage drive is not included.
